HEA/HEB

Grade: Q235 / SS400 / Q345B / S235JR / S275JR / S355JR / A36

Quality: EN10025                      Size Tolerance: EN10034

ITEM

SIZE

(H×B×t1×t2)

(mm)

UNIT

WEIGHT

(Kg/m)

ITEM

SIZE

(H×B×t1×t2)

(mm)

UNIT

WEIGHT

(Kg/m)

HEA100

96X100X5X8

16.7

HEB100

100X100X6X10

20.4

HE120A

114X120X5X8

19.9

HE120B

120X120X6.5X11

26.7

HE140A

133X140X5.5X8.5

24.7

HE140B

140X140X7X12

33.7

HE160A

152X160X6X19

30.4

HE160B

160X160X8X13

42.6

HE180A

171X180X6.0X9.5

35.5

HE180B

180X180X8.5X14

51.2

HE200A

190X200X6.5X10

42.3

HE200B

200X200X9X15

61.3

HE220A

210X220X7X11

50.5

HE220B

220X220X9.5X16

71.5

HE240A

230X240X7.5X12.5

60.3

HE240B

240X240X10X17

83.2

HE260A

250X260X7.5X12.5

68.2

HE260B

260X260X10X17.5

93

HE280A

270X280X8.0X13

76.4

HE280B

280X280X10.5X18

103

HE300A

290X300X8.5X14

88.3

HE300B

300X300X11X19

117

HE320A

310X300X9X15.5

97.6

HE320B

320X300X11.5X20.5

127

HE340A

330X300X9.5X16.5

105

HE340B

340X300X12X21.5

134

HE360A

350X300X10X17.5

112

HE360B

360X300X12.5X22.5

142

HE400A

390X300X11X19

125

HE400B

400X300X13.5X24

155

HE450A

440X300X11.5X21

140

HE450B

450X300X14X26

171

HE500A

490X300X12X23

155

HE500B

500X300X14.5X28

187
